| Item: | Welded Deformed Bar Mesh Panel | Grid Shape: | Square Grid |
|---|---|---|---|
| Material: | Deformed Bar | Mesh Opening: | 100 - 300 Mm |
| Wire Diameter: | 4 - 12 Mm | Maximum Panel Size: | 2.4m X 6m |
| High Light: | concrete reinforcement wire mesh,steel reinforcing mesh |
||
Reinforcing mesh is a welded wire fabric, with rectangular or square grid pattern.
The fabric is used to provide tensile strength and crack control to structural concrete elements.
Reinforcing mesh has a variety of uses for specific applications such as roads, house, foundations, floor, slabs as well as commercial and industrial applications.
Concrete mesh is one of the more common materials used in the construction of commercial buildings.
Feature of Welded Deformed Bar Mesh Panel
| Firm Structure | Wires resist movement |
| Easy handling | Extensive use |
| High strength | Square or rectangular grids |
|
Savings in time, labour and money |
Uniform mesh |
The reinforcing mesh could be custom made by our factory, it is available in various sizes and shapes, the panel could be cutted to the size as your request.
It is widely use in airport, tunnel, bridge, highway and wharf, also in the construction of building floor, wall, roof and balcony.
Specification List
| Mesh Opening | Wire Diamter | ||
|
Pitch of Main Wire mm |
Pitch of Cross Wire mm |
Main Wire Diamter mm |
Cross Wire Diameter mm |
| 200 | 200 | 10 | 10 |
| 200 | 200 | 8 | 8 |
| 200 | 200 | 7 | 7 |
| 200 | 200 | 6 | 6 |
| 100 | 200 | 12 | 8 |
| 100 | 200 | 10 | 8 |
| 100 | 200 | 8 | 8 |
| 100 | 200 | 7 | 7 |
| 100 | 200 | 6 | 7 |
| 100 | 200 | 5 | 7 |
| 100 | 400 | 10 | 6 |
| 100 | 400 | 9 | 6 |
| 100 | 400 | 8 | 6 |
| 100 | 400 | 7 | 6 |
| 100 | 400 | 6 | 6 |
| 100 | 100 | 2.5 | 2.5 |
Packing: on pallet or null packing
Production Process:
Wire Drawing → Wire Straightening & Wire Cutting → Welding→ Packing → Loading
Welding:
Welded wire steel fabric is manufactured with automatic welding machines, where wires are welded together in square or rectangular grids.
