Product Details
Place of Origin: Anping,China
Brand Name: Bingze
Certification: ISO9001-2015
Model Number: GRW20230921
Payment & Shipping Terms
Minimum Order Quantity: 50Roll
Price: 10-50 dollars
Packaging Details: Packing each bundle with anti-rust paper and light oil then wrapped in plastic film or hessians cloth with metallic pallet and put in 20ft or standard sea worthy. ral 3002 ppgi coil, ppgi coil galvanize steel, galvanized steel color coated ppgi coils
Delivery Time: 10-15days
Payment Terms: T/T,L/C,Western Union,MoneyGram
Supply Ability: 15000rolls per month
Material: |
Iron Wire, Q195-Q235 |
Barb Distance: |
26mm-100mm |
Surface Treatment: |
Galvanized |
Wire Diameter: |
2.5mm |
Weight: |
5-20kg/roll |
Barb Spacing: |
25±1, 35±1, 36±1, 46±1, 101±2 |
Material: |
Iron Wire, Q195-Q235 |
Barb Distance: |
26mm-100mm |
Surface Treatment: |
Galvanized |
Wire Diameter: |
2.5mm |
Weight: |
5-20kg/roll |
Barb Spacing: |
25±1, 35±1, 36±1, 46±1, 101±2 |
| Reference Type Number | Thickness | Wire Dia. | Barb Length | Barb width | Barb spacing |
|---|---|---|---|---|---|
| BTO-10 | 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 25±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 25±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 35±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 36±1 |
| BTO-28 | 0.5±0.05 | 2.5 | 28 | 15 | 46±1 |
| BTO-30 | 0.5±0.05 | 2.5 | 30 | 18 | 46±1 |
| CBT-65 | 0.5±0.05 | 2.5±0.1 | 65±1 | 21±1 | 101±2 |
| Outside Diameter | No. of Loops | Standard Length per Coil | Type | Notes |
|---|---|---|---|---|
| 450 mm | 33 | 8M | CBT-65 | Single Coil |
| 500 mm | 41 | 10M | CBT-65 | Single Coil |
| 700 mm | 41 | 10M | CBT-65 | Single Coil |
| 960 mm | 53 | 13M | CBT-65 | Single Coil |
| 500 mm | 102 | 16M | BTO-10,15,22 | Cross type |
| 600 mm | 86 | 14M | BTO-10,15,22 | Cross type |
| 700 mm | 72 | 12M | BTO-10,15,22 | Cross type |
| 800 mm | 64 | 10M | BTO-10,15,22 | Cross type |
| 960 mm | 52 | 9M | BTO-10,15,22 | Cross type |
